Relay Installation Kits
for headlamps and auxiliary lamps

Thin factory wiring starves bulbs!
Click here for more information.
These parts packs help you feed full power to headlamp bulbs. Kits include American and European-made extreme-duty parts to accept your own 10-12ga wire: 30-amp relays with dual output terminals, relay brackets and terminal blocks, terminals, extra-tough fused fuseholders and high-heat headlamp sockets. In most cases, the vehicle's factory wiring remains uncut.

Wire is not supplied because your local economy offers a wide selection of colors and lengths; it's the hardware in these kits that is so hard to find locally.

Buy Them Now

Headlamp Relay Installation Kits

• RIK-1 kit for one sealed beam or H4 headlamp (Motorcycle): $39

• RIK-2 kit for two sealed beam or H4 headlamps: $49

• RIK-2T For Toyota applications: $59

• RIK-4 kit for four sealed beam or H4/H1 headlamps: $59

• RIK-4T For Toyota applications: $69

• RIK-H1H1 kit for four H1 headlamps (Hella BiFocal H1 low beam + parabolic H1 high beam, etc.): $54

• RIK-RAM kit to properly install improved Dodge Ram Sport
  9004/9007 headlamps in place of standard
  1994-2001 Dodge Ram 9004 headlamps: $79

• RIK-HB1 kit for two 9004 headlamps: $59

• RIK-HB34 kit for two 9005 and two 9006 headlamps: $79

• RIK-HB34H as above except safely keeps low beams lit when high beams are on, for systems not originally so wired: $89

• RIK-HB33 kit for four 9005 headlamps (Lincoln Mark VIII, etc.): $79

• RIK-HB5 kit for two 9007 headlamps: $59

• RIK-C5 kit to properly install H4 (export) headlamps
  on 1997-2004 C5 Corvette: $79

• RIK-H4R kit to properly install H4 or 9003 headlamp assemblies in place of 9004 or 9007 headlamp assemblies: $59 (Audi, Mercedes, Subaru, Saab, Volvo, Morette, etc. - Nothing, including this kit, lets you use H4 bulbs in headlamps designed to accept 9004 or 9007 bulbs.

• Don't see what you need? Custom kits are no problem. Just state your need!

Auxiliary Lamp Harnesses and Relay Installation Kits

• RIK-AUX Relay kit for custom installation of two fog or driving lamps, $49.

• H87199 Ready-built, plug-and-chug heavy-duty relay harness for two fog or driving lamps. Very fine quality, includes illuminated toggle switch: $79.

• H87212 Ready-built, plug-and-chug light-duty relay harness for two fog or driving lamps. Good quality, includes easy-mount switch with LED indicator lights: $59.

H1 bulbs

• 55W Narva Rangepower +30: $11.59/ea


• 55W Narva Rangepower +50 *: $15.59/ea


• 100W Narva: $17.59/ea


*- About H1 +50 Bulb Brands:
The H1 +50 bulbs from the big four reputable European bulb makers (Philips VisionPlus, Osram SilverStar, Narva RangePower+50, Tungsram Megalicht) are functionally identical. When we pick ten samples of each and put each one through photometric, optical comparator and life tests, there's a very narrow range of performance and life differences, and those differences are randomized among the four brands.

---




H2 bulbs

These single-filament bulbs are primarily found in auxiliary fog and driving lamps, though there have been a few low-beam and a few high-beam headlamps over the years that used them.
• 55W Narva: $11.59/ea


• 100W Narva: $17.59/ea

---



H3 bulbs

These single-filament bulbs are primarily used in auxiliary fog and driving lamps, but they've also been used in some headlamps, such as certain variants of the Marchal Amplilux. Fun Facts: The H3 was the world's first transverse-filament halogen car bulb, introduced in 1966. The transverse filament and short focal length facilitated the design of certain kinds of lamps that were difficult or impossible to make with axial-filament bulbs. H3 was legalized in the US in 1997, thirty-one years after its European introduction.
• 55W Narva: $9/ea


• 55W Narva Rangepower +50: $15.59/ea


• 100W Narva: $17.59/ea

---




H4 bulbs

These 2-filament bulbs with P43t base are for high/low beam headlamps and Cibie BiOscar fog/drive beam lamps. Fun facts: The H4 was the world's first 2-filament halogen automotive bulb. It was introduced in Europe in 1971, and was used in many millions of European and Japanese headlamps starting in that year, but wasn't legalized in the US (where it was designated HB2 or 9003) until over two decades later, in 1992!
• 60/55W Narva Rangepower High Output +30: $14.59/ea


• 60/55W Narva Rangepower +50 *: $19/ea


• 70/65W Osram Rallye $21.59/ea


• 85/80W Osram Rallye $24.59/ea


• 100/55W Narva or Philips Rallye: $17.59/ea


• 100/90W Narva or Philips Rallye: $20.59/ea


• 130/100W Narva or Philips Rallye: $25.59/ea




*- About H4 +50 Bulb Brands:
The H4 +50 bulbs from the big four reputable European bulb makers (Philips VisionPlus, Osram SilverStar, Narva RangePower+50, Tungsram Megalicht) are functionally identical. When we pick ten samples of each and put each one through photometric, optical comparator and life tests, there's a very narrow range of performance and life differences, and those differences are randomized among the four brands.




---




H4 halogen bulbs on P45t base

Upgrade your vintage European headlamps to modern-car light levels! These updated halogen bulbs (above left) fit and work correctly in all 1950's through 1980's European high/low beam headlamps originally equipped with tungsten R2 bulbs (above right). Light output is much higher, life is much longer.
• 45/40W (original tungsten wattage) Narva: $11.59/ea


• 60/55W (standard halogen wattage)Narva: $14.59/ea


• 100/90W Narva: $21.59/ea


• 130/100W Narva: $24.59/ea

---



H7 bulbs

These single-filament bulbs are found in the low beams, high beams and fog lamps of many European and Japanese vehicles made since the 1990s. Fun Fact: The H7, introduced in 1993, was the first new halogen headlamp bulb design type-approved to Europe's Regulation 37 in twenty years. It touched off a wave of research and development that saw a dozen new halogen bulb types introduced over the next 15 years.
• 55W Narva Rangepower +50 *: $21.99/ea


• 65W Osram Ultra High Output (2100 lumen, H9 burner on H7 base, race and special-purpose use): $24.76/ea Sale! $22.79/ea




* About H7 +50 Bulb Brands:


The H7 +50 bulbs from the big four reputable European bulb makers (Philips VisionPlus, Osram SilverStar, Narva RangePower+50, Tungsram Megalicht) are functionally identical. When we pick ten samples of each and put each one through photometric, optical comparator and life tests, there's a very narrow range of performance and life differences, and those differences are randomized among the four brands.

• Yellow fog beam, black housing:
  $129/ea


• Clear fog beam, black housing:
  $129/ea


• Clear drive beam, black housing:
  $129/ea


• Clear fog beam, chrome housing:
  $129/ea


• Clear drive beam, chrome housing:
  $129/ea



Price includes H2 55W bulb and durable stone shield.

Regulatory compliance:

• ECE (European E-Code) B, HR
• SAE (US and Canada) F, Y

Round Cibie auxiliary lamps

Tango (Series 40)

• Yellow fog beam, black housing:
  $189/ea


• Clear fog beam, black housing:
  $189/ea


• Clear drive beam, black housing:
  $189/ea


• Clear fog beam, chrome housing:
  $189/ea


• Clear drive beam, chrome housing:
  $189/ea



Price includes H2 55W bulb and durable stone shield.

Regulatory compliance:

• ECE (European E-Code) B, HR
• SAE (US and Canada) F, Y

Oscar (Series 180)

• Clear drive beam, black housing:
  $169/ea



Price includes durable stone shield.

Regulatory compliance:

• ECE (European E-Code) B, HR
• SAE (US and Canada) F, Y

OscarPlus+ (Series 190)

• Fog beam, black housing:
  $179/ea


• Drive beam, black housing:
  $179/ea



Price includes durable stone shield.

Regulatory compliance:

• ECE (European E-Code) B, HR
• SAE (US and Canada) F, Y

Super Oscar (Series 200)

• Clear pencil spot beam, black housing:
  $198.29/ea




Regulatory compliance:

• ECE (European E-Code) B, HR
• SAE (US and Canada) F, Y
